Type 1 Battery Energy Storage Connector
A reliable Type 1 connector designed for battery energy storage systems, providing safe, stable, and efficient power connections in high-voltage applications.
-
Designed for Type 1 battery energy storage systems
-
CAE-optimized electrical and thermal performance
-
High-conductivity copper contacts
-
Secure mechanical keying for correct mating
-
Stable operation under continuous high load
CONTACT US
- Product Details
- Application
- Features
- Parameter
- Message
CONTACT US
Connector Introduction
The Type 1 Battery Energy Storage Connector is engineered for safe and efficient electrical connections in battery energy storage systems and new energy applications. Designed with advanced CAE simulation, it meets strict technical requirements for insertion force, insulation resistance, dielectric strength, and temperature rise. The connector supports reliable series connection of battery modules, enhancing worker safety during ESS installation and maintenance. Featuring a robust insulated housing, high-conductivity copper contacts, and mechanical keying to prevent incorrect mating, it ensures stable performance under continuous high-load operation.
Product Applications
Widely used in: new energy vehicle motors, electronic controls, battery PAKs, high-voltage distribution boxes, etc.
Features of Energy Storage Connector
IPX67 professional-grade waterproof. 360-degree rotation: easy wiring, various adjustable angles. Connector insulation uses PA66: high strength, high and low temperature resistant, flame retardant UL94/V0 rating, passed 1000 hours of high and low temperature impact testing. Oxygen-free copper wire conductor uses high-quality oxygen-free copper, good conductivity, low heat generation, suitable for long-term load use. Tight and reliable fit, terminal connection uses: T2 pure copper. Injection molding process, integrated professional mold.
Product Parameter Table
| Terminal | 6mm | Connector Type | Plug |
| Direction | Right Angle | Color | Orange |
| Wire Gauge | 16mm2 | Mounting Type | Cable Mount Receptacle |
| Housing Material | Nylon | Rated Voltage | 1000V |
| Rated Current | 100A | Contact Connection | Silver Plated |
| Insulation Resistance | ≥ 1000MΩ | Flammability Rating | UL94 V-0 |
| Contact Termination | Crimp | Ingress Protection | IP67 |
| Operating Temperature | -40℃~125℃ | Brand | Flash Speed |
